Squaring Around an Edge
-- Joanna Werch Takes Woodworker's Journal April 2003
![](images/red3.jpg) Dimensions: 12-1/2 x 8-1/2 x 1 and 9/16 opening x 3-1/2 inches deep. Made of Rigid Metal.
![](images/red2.jpg) Zero/Zero center finding allows you to mark three workpoints and find center of objects.
![](images/red1.jpg) U.S. Patented. Other Patents pending. 100% Made in USA. Manufactured in Pittsburgh, PA
| ![](images/vsandline.gif) |
Scroll down to view more and to order below.
Click on photos to view larger images.
![](images/notchingsm.jpg) |
Notching out 2x4's one step -- 1-9/16 inch opening by 3-1/2 inches deep |
![](images/6sm.jpg) |
End result! This application can be used in other similar situations |
![](images/2sm.jpg) |
Finding the depth for nail position effectively with no misses |
![](images/7sm.jpg) |
Finding center of hole for workpoint layout. T-Square effect |
![](images/3sm.jpg) |
Finding your quarter points for pipe flange placement |
![](images/8sm.jpg) |
Combination squaring effect for straight line drawing |
![](images/4sm.jpg) |
Press against tread to transfer lines to nearside for nailing |
![](images/9sm.jpg) |
Marking 3 points for centering for base and cap plate fabrication |
![](images/5sm.jpg) |
Transferring lines |
![](images/10sm.jpg) |
Transferring workpoints from farside to nearside |
![](images/16sm.jpg) |
Measuring table-top depth all around for accuracy from top surface |
![](images/11sm.jpg) |
Regular squaring and straight line cuts -- no problem |
![](images/15sm.jpg) |
Notching out stair stringers and easily mark your stair spindles |
![](images/12sm.jpg) |
Measure, mark and square around a flange in one step, no tape needed |
![](images/ewr200x150.jpg) |
Easier when reaching up to square or mark a workpoint |
![](images/13sm.jpg) |
Secondary tongue acts like a handle-like grip for squaring in corners |
![](images/hls200x150.jpg) |
Handle-like squaring -- Tri-square effect. |
![](images/14sm.jpg) |
Three points of center for column fabrication |
Return to Home Page | Features & Applications
Retail price $24.95 + shipping
|
